MINI Controller 0/1-10V - WiFi+RF - PUSH Dim - 100-240V AC - TUYA - Skydance

Name: MINI Controller 0/1-10V - WiFi+RF - PUSH Dim - 100-240V AC - TUYA - Skydance
Brand: Skydance
SKU: SK-L1(WT)
Price: 29.99 EUR
Availability: InStock

SKU:SK-L1(WT)

€29.99 Tax included

In stock 100 units

Data sheet

Dimmer for dimmable LED drivers 0-10V or 1-10V.

It allows dimming from 0 to 100% with a 1 channel 0/1-10V output, compatible with any dimmable LED driver 0-10V or 1-10V. It offers a smooth dimming with 256 levels without flickering.

It includes WiFi control via Tuya Smart and is compatible with Alexa and Google Assistant. It also works as a WiFi-RF converter.

Shipping to Africa available

public

For any shipping requests to Africa, please contact our sales department at: sales@barcelonaled.com

MINI Controller - 0/1-10V: Professional and Versatile Control

This controller offers a comprehensive solution for 0/1-10V dimmable LED luminaires, combining WiFi, RF 2.4GHz and Push-DIM control in one device.

Wide compatibility: Designed for 0-10V or 1-10V dimmable single-color LED drivers and luminaires, selectable by DIP switch.

Smart and remote control: Compatible with Tuya Smart, Alexa and Google Assistant, allowing brightness adjustment, timers, scenes and remote on/off. Can act as a WiFi-RF converter to control other RF dimmers.

Advanced dimming: 0-100% dimming with 256 levels of softness and 3s on/off transition. 0-10V or 1-10V mode selection depending on the driver used.

RF and Push-DIM control: Compatible with RF 2.4GHz single or multi-zone controllers. Incorporates input for external switch, allowing on, off and continuous regulation.
