LED Tube T8 1500mm Glass LED Tube 22W Opal
LED Tube T8 1500mm Glass LED Tube 22W Opal
LED Tube T8 1500mm Glass LED Tube 22W Opal

LED Tube T8 150cm 24W high efficiency 140 LM/W

SKU:B4011-5-150BF

Volume discounts

Quantity Price
25 €8.50
50 €8.41
100 €8.32
200 €8.06
Colour temperature
Has superado el límite de unidades
In stock 3649 unidades

OPAL 150cm 24W Opal, SMD 2835, 230V-AC, angle 330º.

Power factor : 0.95

High efficiency 140 LM/W

Cool white Neutral white Warm white
24W 24W 22W
6000K 4000K 3000K
3455 lm 2917lm 2200 lm

LED T8 150cm 24W 140 LM/W high power factor.

Replaces conventional 150cm / 58W fluorescent tubes.

T8 LED tube, equipped with high brightness SMD 2835 chip and high light transmittance (over 90%) glass and plastic coating, allows uniform light distribution.

  • Wide AC input range from 175V to 265V
  • High power factor up to 0.95
  • Wide opening angle (330º)
  • Glare-free opal coating
  • Short-circuit and overheat protection
  • Including starter jumper
  • Diameter Ø26mm

Equivalences:

  • LED tube T8 150cm 22W Warm white 3000K equivalent to T8 150cm fluorescent 58W/830
  • LED tube T8 150cm 24W Neutral white 4000K equivalent to T8 150cm fluorescent 58W/840 - 58W/845
  • LED Tube T8 150cm 24W Cool White 6000K equivalent to T8 150cm fluorescent 58W/860 - 58W/865

tubo led t8

Download the step by step installation guide from this link.

Installation in ferromagnetic ballasts:

Step 1: Turn off the light at the main switchboard and verify that no electric current is coming.

Step 2: Remove the old tube and then the starter.

Step 3: Put the new LED starter bridge (included with each tube).

Step 4: Remove the capacitor or capacitor (to avoid overvoltage).

Step 5: Install the new LED tube.

Installation in electronic ballasts:

Step 1: Turn off the light at the main electrical panel and verify that no electric current is coming.

Step 2: Remove the old tube (in this case there is no starter, as it is incorporated inside the electronic ballast).

Step 3: Disconnect the cables that enter the electronic ballast (no need to remove it, just disconnect it electrically).

Step 4: Choose one of the 2 tube holders to connect its 2 wires directly to the mains.

Step 5: We recommend to mark the lamp holder where the connection has been made to facilitate the installation of the LED tube.

  • If the installation contains a capacitor bank consult your specialized technician.

Applications:

  • General lighting, direct replacement of conventional 150cm fluorescent tubes.
  • Perfect for illuminating closed parking lots, offices, stores, commercial galleries, kitchens, etc.
  • Thanks to its angle, it is ideal for placement on walls.

tubo led t8 tubo led t8 tubo led t8

Nominal Voltage (V)
220 - 240 V/AC
Kelvin (K)
3000
4000
6000
Beam angle (º)
330
Socket
G13
Lifetime (h)
25000
IP
IP20
Dimensions (mm) Lxlxh
Ø26x1500
Frequency (Hz)
50 - 60
Hue
Cool white
Neutral white
Warm white
Sensor
No
Efficiency (Lm/w)
140
CRI
80-85
UGR
No
LED Type
SMD 2835
Dimmable
No
Power factor (cosφ)
0.95
Driver
Internal
Tube type
T8
Orientable
No
Material
Plastic
Diffuser material
Glass
Use Outdoor
Yes, with waterproof lamps
Frequency of use
Intensive
Energy efficiency class
D
Certificates
CE
ROHS
Warranty
According to legal guarantee: 2 years
