SKU:B4029-120BF
Colour temperature
Has superado el límite de unidades
In stock 181 unidades

LED Tube T5 Opal 16W. LED Tube T5 Opal 16W. The Crystal T5 LED Tube has two side connections for easy installation, emits a powerful illumination and low power consumption, contains 16W that provide us with an illumination equivalent to conventional fluorescent tubes.

✔ Opal Coverage: It does not emit glare.
Overheating and short circuit protection.
✔ Opening angle 300º.
✔ Instant on
✔ Flicker-free

LED T5 Opal Tube 120cm (1165mm)

Replace conventional fluorescent tubes with LED T5 tubes!

The T5 Crystal LED Tube T5has two G5 side connections for easy installation, emits powerful illumination and low power consumption, and contains 16W which provides illumination equivalent to conventional fluorescent tubes.

The 1200mm T5 LED tube is made of opal glass with class A+ energy efficiency. In addition, it emits a light opening angle of 300°, which is ideal for illuminating large spaces.

Features of Opal T5 LED Tube Light

✔ Opal Coverage: No glare emission.
✔ Overheating and short circuit protection.
300º opening angle
✔ Instant on

Technical installation

STEP 1: Turn off the light at the electrical main switchboard and verify that no electric current is coming.

STEP 2: Take out the old tube (in this case there is no starter, as it is incorporated inside the electronic ballast).

STEP 3: Disconnect the cables that enter the electronic ballast (no need to remove it, just disconnect it electrically).

STEP 4: Connect phase to one side of the connection and connect neutral to the mains on the other side.

  • IF THE INSTALLATION CONTAINS A CAPACITOR BANK, CONSULT WITH YOUR SPECIALIZED TECHNICIAN.

Applications of Opal T5 LED Tube Light:

✔ Shops
✔ Offices
✔ Kitchens
✔ Commercial galleries

Tubo LED T5 120cm Opal para iluminación interior

You may also be interested in...

We have a wide range of LED tubes, among which you can find different sizes, 60cm T5 LED tubes or 150cm T5 LED tubes.

Nominal Voltage (V)
230
Lumens (Lm)
1954
Kelvin (K)
4000
6000
Beam angle (º)
300
Socket
G5
Lifetime (h)
25000
IP
IP20
Dimensions (mm) Lxlxh
Øx1165
Frequency (Hz)
50 - 60
Hue
Cool white
Neutral white
Detection angle (º)
No
Detection range (m)
No
Sensor
No
Efficiency (Lm/w)
122
CRI
80-85
UGR
< UGR19
LED Type
SMD 2835
Dimmable
No
Equivalence (W)
30
Power factor (cosφ)
0,95
Driver
Internal
Tube type
T5
Orientable
No
Material
Plastic
Diffuser material
Crystal
Use Outdoor
Yes, with waterproof lamps
Temperature range
No
Frequency of use
Intensive
Energy efficiency class
A+
Certificates
CE
ROHS
Warranty
3 years
