Smart LED Strip IC RGB 12V DC - 14,4 W/m -IP20 - 60 LED/m - Width 10mm - 5 meters

SKU:B1576RGB
Has superado el límite de unidades
In stock 269 unidades

The intelligent RGB LED strip (IC) is designed to operate with 12V DC voltage. Each LED chip has its own SMD5050 light source and integrated driver (IC), allowing individual control of each LED in the strip. In this way, the WS2812B LED strip can be programmed to create complex light patterns and custom animation effects.

In addition, the strip can be extended and cut every 16 mm, giving it great versatility.

It is IP20 rated, making it suitable for indoor use.

The intelligent LED strip IC allows you to control each LED individually. It is ideal for decoration of hotels, bars, all kinds of events, or as a replacement for traditional neon lights.

The IC chip used in this strip is WS2812B, with low power consumption and high efficiency, which enables intelligent RGB lighting control.

With a beam opening angle of 120° and a voltage of 12V, the strip features 300 high quality integrated SMD 5050 RGB RGB SMD LED lights.

The individual control of each chip offers multiple LED lighting possibilities, allowing you to create eye-catching visual effects. In addition, these RGB IC RGB LED strips are easy to program and work well with many types of controllers to create the desired effect every time.

The LED strip is self-adhesive on the back and comes on a 5 meter reel with an IP20 protection rating.

It is possible to cut the strip every 16mm, which allows great versatility for different applications.

The wires of the LED strip are made of high quality copper and have excellent conductivity, which ensures stable and uniform illumination. The outer layer of the strip is made of PVC, which makes it eco-friendly and durable, and provides it with a very long service life.

Main product features:

  • Voltage: 12V DC
  • Power: 72W (14.4W/m)
  • Width: 10mm
  • Length: 5m
  • IP20: indoor use
  • SMD5050 RGB
  • 60ch/m
  • WS2812B IC
  • 8 bits green, red and blue shifted to 24 bit color
  • Cut-off distance: 16mm

B1576RGB strip connection

Power supply:

  • Positive 12V: RED wire
  • Negative: BLACK wire

Connector:

  • Positive 12v: RED Wire
  • DI DATA: GREEN Wire
  • Negative: WHITE Wire
  • BI DATA: Connection to Negative

Nominal Voltage (V)
12V-DC
Power (W)
72
Beam angle (º)
120
IP
IP20
No. of chips/metre
60
Adhesive
3M
Certificates
CE
ROHS
