LED Strip 24V-DC 72W multicolor RGB IP67 Roll 5 meters
SKU:B1549-IP67
€32.45
Tax included
The 24V RGB LED Strip is the ideal model for those who want to create colorful environments.
The RGB LED strips at 24V with SMD 5050 chip produce a beautiful surrounding light in each of the colors they achieve. With 24V RGB LED strips you can connect up to a maximum of 10 linear meters to a single controller and a single power supply, twice as much as with 24V strips.
This range of professional RGB LED strips has 60 chips per meter, achieving a totally homogeneous beam. The LED or RGB strip can produce almost any color of light imaginable, the limitation is always set by the RGB controller to which it is connected (the controller is sold separately).
It is highly recommended to install the strips in specific aluminum profiles for proper heat dissipation and to prolong its life.
Advantages:
- Very flexible to be able to make an installation to suit your needs.
- High brightness and luminosity.
- Requires 24V power supply and RGB controller (sold separately).
You can choose the degree of impermeability of the strip between IP20, IP65 and IP67.
> Profiles for LED strips, highly recommended for installation as they are not self-adhesive.
2018-07-08
Nominal Voltage (V)
24V-DC
Power (W)
72
Power/m (W/m)
14,4
Beam angle (º)
120
Lifetime (h)
25000
IP
IP67
Dimensions (mm) Lxlxh
5000x10
Frequency (Hz)
50 - 60
Hue
RGB
LED Type
SMD 5050
Dimmable
Yes
No. of chips/metre
60
Track width (mm)
10
Cutting distance (mm)
100
Use Outdoor
Yes
Adhesive
No
Energy efficiency class
A+ (2021)
Certificates
CE
ROHS
ROHS
Warranty
According to legal guarantee: 2 years
Questions
| P: Pregunta: | Do you have any connector to use with these LED strips and in turn to connect them to 24V relays that go to a PLC? In my case we already have our own 24V source, and the relays. |
|---|
| R: Respuesta: | You can use the model SDN10XB-4W200
Barcelona LED: Javier| el 17 de September de 2023 |
|---|
