220V AC COB LED Strip - 10W/m - 12mm - IP67 - 5 meters

SKU:B1536-5-BF

Volume discounts

Quantity Price
3 €24.24
6 €23.74
9 €23.24
12 €22.49
Colour temperature
Has superado el límite de unidades
In stock 182 units
Data sheet

The COB 220V AC COB LED strip stands out for its bright and uniform illumination, with no shadows or visible light spots, unlike traditional LED strips.

It has a total width of 12mm (PCB: 10.5mm) and its great flexibility allows easy installation in any space. It can be cut every 50 cm and has a CRI>90.

Incorporating COB technology, it has a high luminous efficiency of 100lm/W, with a density of 288 chips/meter.

Due to its IP67 degree of protection , it is suitable for outdoor installation.

It is available in warm white (2700K), neutral white (4000K) and cool white (6000K).

Shipping to Africa available
public
For any shipping requests to Africa, please contact our sales department at:  sales@barcelonaled.com

This LED strip incorporates COB technology, which allows it to emit a continuous light, without visible points, especially recommended when homogeneous illumination is desired, to work with reflective surfaces or to use transparent diffusers.

With a luminous intensity of 10W per meter, this strip provides exceptional brightness, superior to conventional LED strips.

The LED strip comes in a roll of 5 meters and allows cuts every 50cm, according to the indicated markings. It incorporates 3M self-adhesive on the back to adhere to the desired surface.

For its correct operation, it requires a rectifier that converts alternating current into direct current (Compatible reference: B1536-CI-EU).

In addition, for installation, it is recommended to use the specific connectors corresponding to our references: B1536-TT (strip-to-strip connector), B1536-CTT (strip-to-strip connector with cable) and B1536-L (90º connector).

Main characteristics of the product:

  • Voltage: 220 V AC
  • Efficiency: 100lm/W
  • Power: 10W/m
  • Opening angle: 120°.
  • Total width: 12mm
  • PCB width: 10,5mm
  • Cutting distance: 500mm
  • IP67: outdoor use
  • Strip length: 5 meters
  • LED chips: COB (288chips/m)
  • Available in shades: warm white (2700K), neutral white (4000K) and cool white (6000K)
  • Dimensions: 12x5000mm

Please note that certain technical characteristics such as power or efficiency may vary according to the color/shade of the product. For further information, please consult the attached test reports in the "Downloads" section, or contact our sales advisors.

Nominal Voltage (V)
220 - 240 V/AC
Power/m (W/m)
10
Kelvin (K)
2700
4000
6000
Beam angle (º)
120
IP
IP67
Dimensions (mm) Lxlxh
12x5000mm
Hue
Cool white
Neutral white
Warm white
Efficiency (Lm/w)
100
CRI
90-95
LED Type
COB
Dimmable
No
No. of chips/metre
288
Track width (mm)
12
Cutting distance (mm)
1000
Use Outdoor
Yes
Adhesive
3M
Certificates
CE
ROHS
Warranty
According to legal guarantee: 2 years
